C058940M102A 1 Box = 2EA - ePMP 5 GHz Force 425 SM 2-pack packaging priced per radio (FCC) (US Cord)

New: C058940M102A 1 Box = 2EA - ePMP 5 GHz Force 425 SM 2-pack packaging priced per radio (FCC) (US Cord) The Cambium Force 425 is an enterprise-grade, point-to-point (PTP) and high-capacity subscriber module solution designed on the 802.11ax (Wi-Fi 6) standard. By pairing Wi-Fi 6 hardware with Cambium's proprietary ePTP wireless protocol, it achieves fiber-like capacities over the air at a significantly lower cost than licensed microwave frequencies. It features an integrated 25 dBi dish antenna to cut through heavy wireless interference, making it ideal for service providers delivering high-capacity business links, MicroPOP backhauls, or Wi-Fi hotspot extensions. For long-distance or challenging links, it includes a built-in SFP port for direct fiber extensions and support for field-upgradable 28 dBi range extenders. Technical Specifications Summary Feature Specification Details Maximum Capacity Up to 1 Gbps symmetrical aggregate throughput Wireless Protocol Proprietary ePTP & 802.11ax (2x2 MIMO/OFDM) Frequency Range 4920 – 5885 MHz (FCC/US regulatory limits) Channel Spacing Configurable in 5 MHz increments Channel Widths 20 MHz, 40 MHz, and 80 MHz Latency < 5 ms (highly consistent frame execution) Modulation Levels Up to 1024 QAM (Adaptive MCS 0 to MCS 11) Peak Gain 25 dBi integrated dish antenna Beamwidth 7° Azimuth / 7° Elevation Encryption / Security 128-bit AES hardware encryption (256-bit software upgradeable) Interfaces 1 x 10/100/1000 Base-T RJ-45 Port, 1 x 10G SFP Port cage Environmental & Mechanical • Ruggedization: Fully IP67 rated for absolute dust and water sealing. • Operating Temperature: -30°C to 65°C (-22°F to 149°F). • Wind Survival: Tested to withstand up to 180 km/h (112 mph). • Power Consumption: Maximum 28 W per radio unit using passive PoE injection. • Surge Suppression: Built-in 1 Joule protection
